For Lead-acid batteries > Regenerator > For 6V.8V.12V
RPT-A300
For all types of Lead-Acid Batteries
3-in-1 Multifunctional
· High-Frequency Regenerator
· Smart Charger
· DC Power Supply
· Smart Charger
· DC Power Supply
Key Points
| Industry-Leading Power-to-Size Ratio: Delivers true industrial-grade performance in a ultra-compact, portable form factor. |
| Maximum Efficiency & Speed: Fully restores and charges a 12V 250Ah battery in just 15 hours without requiring chemical additives or repeat cycles. |
| Advanced PRIME Regeneration Tech: Engineered with PRIME’s latest high-output technology, outperforming traditional, bulky restoration systems. |
| Performance & Technology |
| 3-in-1 Multifunctional System: Combines battery regeneration, charging, and power output into a single compact unit. |
| High Real Output Current: Delivers up to 25A of actual regeneration current for rapid recovery. |
| Simultaneous Operation: Restores and charges batteries concurrently to maximize productivity. |
| Additive-Free Process: Restores battery capacity through high-frequency pulsing technology—no chemical agents needed. |
| Technical Specifications |
| DC Output Voltage: DC 6V, 8V,12V (adjustable) |
| Output Current: Max. 25A (precise micro-control tailored to battery type) |
| Battery Capacity Range: 40Ah ~ 300Ah |
| AC Input Power: AC 100V ~ 240V / 50Hz ~ 60Hz |
| Power Consumption: 0.5kWh |
| Safety & Smart Control |
| Thermal Protection: Prevents temperature spikes through active output voltage/current regulation. |
| Over-Voltage & Line Protection: Input over-voltage protection and voltage variation stabilization to prevent potential thermal hazards. |
| Interface: Smart MICOM control system paired |
| Portability: Portable design optimized for field maintenance and worldwide operating conditions. |
| Dimensions (WxDxH): 235 × 380 × 170mm (9.3 × 15.0 × 6.7 in) |
| Weight: Approx. 6.6 kg (14.5 lbs) (Body and Cable) |
| Cable Included: 25 mm² (25SQ) Battery Cable (2.0 m / 6.6 ft) |
| Technical Specifications |
| DC Output Voltage: DC 6V, 8V, 12V (adjustable) |
| Output Current: Max. 25A (precise micro-control tailored to battery type) |
| Battery Capacity Range: 40Ah ~ 300Ah |
| AC Input Power: AC 100V ~ 240V / 50Hz ~ 60Hz |
| Power Consumption: 0.5kWh |
